2024 Ducati Hypermotard 698 Mono at Steele Recreation

Standard

• Engine: Superquadro Mono, single-cylinder, 4 valves per cylinder, Desmodromic valve timing, 2-balancer countershaft, liquid-cooled
• Displacement : 659 cc
• Compression ratio : 13,1:1
• Power: 77.5 hp (57 kW) @ 9,750 rpm
• Torque : 46.5 lb-ft (63 Nm) @ 8,000 rpm
• Injection: Electronic injection, 62 mm throttle body with Ride by Wire system
• Exhaust: Catalyzed 1-2 exhaust with double aluminum outlet and lamba probe

Standard

• Gearbox : 6 speed
• Primary drive: Spur gear; ratio 1.968:1
• Ratio : 1=36/13 2=35/17 3=32/20 4=29/22 5=24/21 6=26/25
• Final drive: 520 chain; Gearbox sprocket 15; Rear sprocket 42
• Clutch: oil-immersed, hydraulically controlled, limited-slip, auto-servo multi-plate clutch

Standard

• Frame: Tubular frame
• Front suspension : Fully adjustable 45-mm Marzocchi aluminium upside-down forks
• Front wheel: 3.5" x 17" 5-spoke Y-spoke light-alloy wheel
• Front tire : Pirelli Diablo Rosso III, 120/70 ZR17
• Rear suspension: Aluminum swingarm Fully adjustable Sachs rear monoshock
• Rear wheel: Lightweight 5-spoke Y-alloy, 5.0" x 17".
• Rear tire ¨: Pirelli Diablo Rosso IV, 160/60 ZR17
• Wheel travel (front/rear): 8.5 in (215 mm) - 9.4 in (240 mm)
• Front brake: 330 mm aluminum disc, Brembo M4.32 caliper, radial pump with adjustable lever, with Bosch Cornering ABS
• Rear brake: 245 mm diameter disc, single-piston floating caliper, with Bosch Cornerin ABS
• Instrument panel: 3.8" LCD display with IBN (Improved Black Nematic) technology

Standard

• Safety equipment: Driving modes, ABS Bosch Cornering, Ducati Traction Control (DTC), Ducati Wheelie Control (DWC), Engine Brake Control (EBC), Ducati Brake Light (DBL)
• Standard equipment: Power modes, Ducati Launch Control (DLC), Full LED lighting system, Daytime Running Lights (DRL), Aluminium handlebars with variable cross-section, Lithium-ion battery
• Standard equipment : Power Modes, Day Time Running Light (DRL), Ducati Quick Shift (DQS) up/down EVO, Marchesini forged wheels, Tapered aluminum handlebars, Removable passenger footpegs, USB power socket, Carbon fibre components: front mudguard, timing belt covers
• Equipment provided: Passenger foot-rest
• Pre-equipment: Anti-theft system, Ducati Quick Shift (DQS) Up/Down, heated grips, Ducati Multimedia System (DMS).

Standard

• Number of Seats : 2
• Curb Weight : 333 lb (151 kg)
• Hauteur de selle : 35.6 in (904 mm), 35.0 in (889 mm) avec l'accessoire siège bas
• Wheelbase : 56.8 in (1,443 mm)
• Rake : 26.1°
• Trail : 4.2 in (108 mm)
• Fuel Tank Capacity : 12 l ( 3 US gal)

Standard

• Warranty : 24 months unlimited mileage
• Maintenance Service Intervals : 15,000 km (9,000 mi)/12 months
• Valve clearance adjustment : 30,000 km (18,000 mi
